Pulse Oximeter

Arterial oxygen saturation (SpO2) as a possible vital sign in acute illnesses.Respiratory diseases such as asthma, COPD, Covid-19 and other lung diseases can can cause a decrease in blood oxygen saturation. With this small pulse oximeter, you can easily determine arterial oxygen saturation (SpO2) and heart rate. The device is compact and lightweight, making it suitable for home use and travelling.


  • For control and regular monitoring of oxygen saturation
  • Determination of heart rate (pulse) and perfusion index (PI)
  • Graphic pulse display
  • Pulse oximeters are suitable for all ages, from children to the elderly.
  • Easy to use: With one button measurement
  • Small and light - for at home and on the go
  • high-resolution OLED screen
  • Automatic switch-off
  • Battery change indicator
  • incl.Lanyard


Technical Details

Item Content
Classification Medical Device
models C101H1
Dimension 60*35*35mm
Weight Approx. 60g
Type of protection against electric shock: Internally powered equipment
Degree of protection against electric shock: Type BF
Protection Against Ingress of Liquids: lp22 (protected against ingress of water when the water is dripping vertically and the monitor is tilted up to 15°)
Mode of operation: Continuous
Expected Service Life: 5 years
Display Type: OLED-Display
Sp02: Measurement range:70%-99%；Accuracy: ±2% on the stage of 70%-99%, Unspecified (≤70%)；Resolution:±1%
PR: Measurement range: 30BPM-240BPM； Accuracy:±2BPM or ±2%
Working Power: Power Supply :2*AAA 1.5V batteries； Electric Current:≤ 50mA;
Battery life: 2 AAA 1.5 V alkaline battery can be used for 30 hours continuously;
Battery voltage: Low battery indicator appears before battery power is lowered to normal operation
Operation Temperature +5°C ~ +40°C
Storage Temperature -10°C ~ +40°C
Operation Humidity 15%~80%
Storage Humidity 15%~80%
Air Pressure 70kPa ~106kPa
EAN 4260620740199

Downloads

User Manual (EN) Benutzeranweisung (DE)

The English document instructions of use includes multiple models of the product. Please refer the technical specifications of the product in Technische Details table.
